224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯并网发电用打火机汽柴油经济发展性好: 高端的汽柴油掌控模式，才有的STC、ESTC 分级管理掌控模式，比较特殊设定的活塞件表层然烧室，高电压引射汽柴油，全面吸雾，然烧全面。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯发电站用热车机瞬态性能方面比较好: 完善的热车机布局的设计，互相配合康明斯特殊的EFC系统软件，操控精度等级高，积极地响应事件快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯发电量用热车机升最大功率高: 整体布局规划密集.形壮布置房间节省，运作有序。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷门焊机 QSNT. QSK19. QSK38. QSK50需求国家非路途三、价段及北美地区Tier2. Tier 3尾气排放法律法规符合要求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零零部件而犯性好， 汽车发主观因素启动及维护的保养的保养社区便利店，料工费低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

额定功率范围图 Power Range   224-310KW类型 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L样貌长宽高 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净安全性能 Dry Weight   940kg

224-310KW康明斯带发电用打火机的优点和缺点：大小小， 缩减变高， 集水管暖空气高温，有利于进行，电信车载电子供电的第一选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

起倾向款式	长用最大功率(kW)Prime Power	预备电率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
